Behotec Turbine JB-180-Gold Edition RC Jet Turbines manufacturer from Australia ARVIERA

Behotec Turbine JB-180-Gold Edition RC Jet Turbines

Price:	3600.0~3700.0 USD
Payment Terms:	T/T


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Power: Fuel

Brand Name: Behotec

Type: Plane

Brand New

The JB180 Gold Edition is based up the advancement of the legendary JB180. The turbine is equipped with a 5 axle CNC milled compressor. This is made of special high-strength aluminum alloy. The new combustion chamber, compressor and the new electronic spend a very fast acceleration, excelent quiet running, as well as extraordinary dynamics to the turbine. The engine is provided as a standard with a starter and with all accessories necessary for the installation less battery. Test run certificate, delivered. The turbine is only available with kerosene start. The kerosene burner is fully integrated. The provided ECU (Electronic Controll Unit) is using a special software for the JB180-Gold edition and need only one receiving channel. For current supply we recommend a 3S Lipo with ca.2500mAh and max.12Volts. We give two years to warranty on the complete turbine.

proven design, very maintenance-poor
easy operation through integrated 12 V kerosene burner
autocalibration, turbine calibrates itself automatically
optimized kerosene consumption with approx. 500 - 550ml/min
super fast acceleration, very dynamically

Technical data:
Diameter
113 mm
Length
320 mm
Weight
1580g – 3,5lbs
max. thrust
180N – 40,50lbs * 120,000 rpm
min. thrust
8,0N – 1,6~1,75lbs * 35,000 rpm
Fuel consumption *max. thrust
550 ml/min
Exhaust gas temperature* max. thrust
arround 680°
Fuel
Diesel or Jet A1 (+5% turbine oil)
Acceleration 35.000 – 120.000 rpm
3 seconds aprox.
Acceleration 60.000 – 120.000 rpm
1 second aprox.
